24″ high x 24″ wide (61 cm x 61 cm) panels for linear, surround, and root pruning applications. Each panel includes a patented, integrated zipper joining mechanism for easy assembly. The 24″ (61 cm) height is ideal for protection from aggressive, invasive roots in sidewalks, curbs and gutters, driveways, and patios, as well and many other planting situations.
Panel Details
Our panels are designed to be strong, effective, and easy to use.

Double Top Edge

Rounded Edges

Ground Locks

Zipper Joiner

90° Rib
Features
- Instant assembly: panels slide together with a zipper joiner system
- Universal Guide: linear, surround, and root pruning applications
- Sizing adjustable in 2′ (61 cm) modules
- 1/2″ (1.2 cm) raised 90º molded root deflecting ribs
- Ground lock tabs to prevent lifting by tree
- Double top edge for strength, safety, appearance and root overgrowth protection
- Ultraviolet inhibitors
- Rounded edges for safety in handling
- Manufactured in USA with 90% reprocessed polypropylene
- DeepRoot products are protected under one or more of the following U.S. Patents: 5,070,642; 5,305,549 and 5,528,857
Assembly
Panel Dimensions
24″ H x 24″ W (61 cm x 61 cm)
Materials and Manufacturing Process
- Copolymer Polypropylene of 0.080″ (2.032 mm) thickness
- 75% reprocessed polypropylene
- Injection molded
- IS0 9002 certified
- Made in USA
Packaging
20 Panels (40 linear ft. / 12.2 m) per carton
20 cartons per pallet, approximately 43 lbs. (19.5 kg) per carton
Specifications Properties
TEST |
ASTM TEST METHOD |
VALUE COPOLYMER POLYPROPYLENE |
Tensile stress @ yield |
D638 |
3800 PSI (26,200 kPa or kN/m²) |
Elongation @ yield |
D638 |
6.3% |
Flexural Modulus |
D790B |
155,000 PSI (1,068,687 kPa or kN/m²) |
Notched Izod Impact |
D256A |
7.1 |
Rockwell Hardness r-scale |
D785A |
68 |
