WHAT ARE GEOMEMBRANES?

GEOMEMBRANE

geomembrane water barrierwater barrier

WATER BARRIER

WB 18/30, WB 24/30, WB 24/40, WB 30/30,WB 30/40,
WB 30/60, WB 36/30, WB 36/60, WB 48/30
Versatile DeepRoot Water Barriers protect hardscapes and landscapes from subterranean water movement. When used around building foundations Water Barriers prevent root intrusion and maintain water equilibrium. The impermeable geomembrane is also ideal for golf course construction to separate the greens from invasive grass and clay soils.
FEATURES
  • Cuts at any measured length with utility knife
  • Up to 300 linear feet (91.44 m) without the need for a seam
  • Joins vertically or horizontally with sealant tape
  • Additional depths with vertical use or horizontal overlapping
  • Made in the USA

Caution: The DeepRoot Water Barrier will not turn tree roots downward for subsequent lateral growth, which firmly anchors the tree. If the water barrier is to be used near a tree a local arborist should be consulted.
DIMENSIONS
0.030" (0.76 mm) Thickness Rolls:
  • WB 18/30: 18" x 300' (46 cm x 91.44 m)
  • WB 24/30: 24" x 300' (61 cm x 91.44 m)
  • WB 30/30: 30" x 300' (76 cm x 91.44 m)
  • WB 36/30: 36" x 300' (91 cm x 91.44 m)
  • WB 48/30: 48" x 300' (122 cm x 91.44 m)

0.040" (1.02 mm) Thickness Rolls:
  • WB 24/40: 24" x 300' (61 cm x 91.44 m)
  • WB 30/40: 30" x 300' (76 cm x 91.44 m)

0.060" (1.524 mm) Thickness Rolls:
  • WB 30/60: 30" x 300' (76 cm x 91.44 m)
  • WB 36/60: 36" x 300' (91 cm x 91.44 m)

*If there’s a size or thickness of Water Barrier you don’t see here that you’d like, please let us know and we’ll do our best to accommodate your needs.
MATERIAL AND MANUFACTURING PROCESS:
  • Polyethylene (HDPE) of 0.030" - (0.76 mm) thickness, 0.040" - (1.02 mm) thickness or 0.060" - (1.524 mm) thickness
  • Recyclable sheet material
  • Minimum of 75% post-consumer recycled content
SHIPPING
WB 18/30: Approx. 75 lbs. (34.02 kg) per roll
WB 24/30: Approx. 100 lbs. (45.36 kg) per roll
WB 24/40: Approx. 133 lbs. (60.33 kg) per roll
WB 30/30: Approx. 125 lbs. (56.70 kg) per roll
WB 30/40: Approx. 166 lbs. (75.30 kg) per roll
WB 36/30: Approx. 150 lbs. (68.04 kg) per roll
WB 36/60: Approx. 300 lbs. (136.07 kg) per roll
WB 48/30: Approx. 200 lbs. (90.64 kg) per roll
SPECIFICATIONS
High Density Polyethylene 30 mil, 40 mil, 60 mil (HDPE)
GEOMEMBRANE PROPERTIES (30 MIL).  **PROPERTIES FOR 40 MIL AND 60 MIL BY REQUEST**
TEST
MD Break Strength ( psi )
TD Break Strength ( psi )
MD Break Elongation ( % )
TD Break Elongation ( % )
Puncture Strength ( lbs )
MD Tear Strength ( lbs )
68TD Tear Strength ( lbs )
Hydrostatic Resistance ( psi )
ASTM TEST METHOD
D638
D638
D638
D638
D4833
D1004
D1004
D751, Procedure A
MEAN VALUE
3735 psi (25,752 kPa or kN/m²)
3877 psi (26,731 kPa or kN/m²)
611%
737%
80 lbs. (36 kg)
31 lbs. (14 kg)
33 lbs. (15 kg)
294 psi (2,027 kPa or kN/m²)
